Solid X3 High Bay On-Off 120Llm/W 100W-12000lm 90º 4000K
Ref. Lyco: NLY0012566
Colour Temperature No Flicker Cool White 4000K
30 Day Return
Under our Change Your Mind Guarantee you can return your item within 30 days for a refund using our hassle free return portal.
For more information view our Returns policy.
Want your items fast?
Check our delivery cut-off times below:
Mon – Thu: Order before 8:45 PM for 24/48h delivery.
Friday: Order before 3:00 PM for 24/48h delivery.
Full conditions here: Delivery methods.
100% secure payments
At Lyco we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation
Up to 5 year warranty
Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.
You will find the exact product warranty in the technical details.
Dimensions
- Diameter236 mm
- Height80 mm
Certificates and Stamps
Technical Specifications
Electrical Features
- DimmableNo
- Electrical Insulation ClassI
- Frequency50-60 Hz
- Nominal Voltage220 V - 240 VMinimum and maximum voltage fluctuation that the product can withstand momentarily.
- Overvoltage Protection2 kVProduct's ability to withstand voltage spikes or electrical overloads, protecting internal components from potential damage due to current fluctuations.
- Replaceable Light SourceYes
- Voltage Range220-240V ACVoltage level required for the product to function correctly.
- Wattage100 W
Mechanical Features
- Coastal ResistantNo
- IK ProtectionIK07Protection grade that the product offers against physical impacts. It is measured on a scale from IK00 to IK10, with IK10 being the highest level of resistance to impact and mechanical damage.
- InstallationPendant, Wall, Surface
- IP RatingIP65The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
- LocationIndoor
- Optic90ºType of lens that determines the distribution and quality of the light. It influences the illumination angle and light efficiency.
- Working Temperature-20 °C~+40 °CInternal temperature range in which the product can operate efficiently and safely. It is important to ensure its reliability under different usage conditions.
LED Features
- Beam Angle90ºMeasures in degrees how light spreads from the source. A wide angle covers more area, while a narrow one is ideal for highlighting details.
- Colour Rendering Index80Measures how accurately a light source displays colours compared to natural light. A high CRI (close to 100) ensures accurate colour rendering.
- Colour Temperature4000KDefines the light tone, from warm white to cool white, measured in Kelvin (K).
- Glare FactorUGR <22Low-glare products offer more comfortable lighting, suitable for extended use.
- Hours40.000 hoursEstimated lifespan of the product before it loses performance. Based on optimal, non-continuous use, and measured in hours of operation under controlled conditions.
- LED Performance130 lm/WEfficiency of the LEDs, measured as the amount of light generated per unit of energy consumed (lumens per watt). High efficiency ensures energy savings without losing light quality.
- Light ColourCool White
- Lumen12000 lm
- Luminous Efficiency120 lm/WRatio between light output (lumens) and energy consumed (watts). A high value indicates better efficiency, ideal for saving energy without compromising lighting.
- Number of LEDs144
- Power Factor0.98
Product Information
- BrandEnvirolight
- CertificatesCE, RoHS, UKCA
- Guarantee3 years
- Product SeriesSolid X3
Product Data
- Product FormatHigh Bay Lighting
- Product typeIndustrial Highbays
Materials and Finishes
- ColourBlack
- Fitting MaterialAluminium
Key Features
High-performance industrial high bay luminaire delivering 12,000 lumens at 100W with exceptional luminous efficacy of 120 lm/W. Features a robust die-cast aluminium housing rated IP65 and IK07 for superior protection against dust, water ingress, and mechanical impact, ensuring reliable operation in demanding indoor and outdoor industrial environments. Provides a 90º beam angle with UGR <22 for optimal glare control and uniform illumination. Colour temperature is 4000K (cool white) with a Colour Rendering Index (CRI) of 80, suitable for precise colour discrimination in production and logistics settings. Operates at a power factor of 0.98 and frequency range 50-60 Hz, with overvoltage protection up to 2 kV. Designed for pendant or surface mounting with a compact form factor (80 mm height, 236 mm diameter) and a durable aluminium construction for long-term stability. Rated for continuous operation between -20 °C and +40 °C, with a lifespan of 40,000 hours. Non-dimmable with integrated LED array of 144 LEDs, ensuring consistent luminous performance of 130 lm/W. Certified to CE, RoHS, and UKCA standards, providing trusted quality and compliance for professional industrial applications.
Description
Robust 100W UFO LED High Bay luminaire engineered for industrial and logistics environments, featuring a die-cast aluminium housing with IP65 and IK07 ratings for superior protection against dust, moisture, and mechanical impact. Delivers high luminous efficiency of 120 lm/W with a total output of 12,000 lumens from 144 LEDs, ensuring energy-efficient and powerful illumination. Equipped with a 90° beam angle optic for wide, controlled light distribution and UGR <22 for reduced glare, optimising visual comfort in professional workspaces. The fixture operates at 4000K colour temperature with a CRI of 80 for accurate colour rendering critical in production and logistics settings. Designed for reliable performance within -20 °C to +40 °C ambient temperatures, it includes 2 kV overvoltage protection and stable, flicker-free DOB technology. Installation is flexible via pendant or surface mounting. Certified to CE, RoHS, and UKCA standards, this luminaire offers durable, efficient, and dependable lighting tailored for demanding industrial applications.
