150W-30,000lm 4000K 120º DALI Sensorless

Ref. Lyco: NLY0013336

Wattage 150 W

Colour Temperature Cool White 4000K

    Optic 120º

      VAT not included £62.91

      £75.49

      Energetic efficiency
      Product information sheet

      Delivered in 8 to 14 working days

        30 Day Credit Terms

        • 30 Day Return

          Under our Change Your Mind Guarantee you can return your item within 30 days for a refund using our hassle free return portal.


          For more information view our Returns policy.

        • Want your items fast?

          Check our delivery cut-off times below:


          Mon – Thu: Order before 8:45 PM for 24/48h delivery.


          Friday: Order before 3:00 PM for 24/48h delivery.


          Full conditions here: Delivery methods.

        • 100% secure payments

          payment method image 1

          payment method image 2

          At Lyco we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation

        • Up to 5 year warranty

          Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.


          You will find the exact product warranty in the technical details.

      Dimensions

      • Diameter300 mm

      Certificates and Stamps

      CertificateCertificateCertificateCertificate

      Technical Specifications

      • Electrical Features

        • DimmableYes
        • Electrical Insulation ClassI
        • Frequency50-60 Hz
        • Light SourceLUMILEDS SMD2835
        • Minimum and maximum voltage fluctuation that the product can withstand momentarily.
          Nominal Voltage120 V - 277 V
        • Type Of DimmingDALI 2
        • Voltage level required for the product to function correctly.
          Voltage Range220-240V AC
        • Wattage150 W

      • Mechanical Features

        • Coastal ResistantNo
        • Protection grade that the product offers against physical impacts. It is measured on a scale from IK00 to IK10, with IK10 being the highest level of resistance to impact and mechanical damage.
          IK ProtectionIK08
        • The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
          IP RatingIP65
        • LocationIndoor
        • Type of lens that determines the distribution and quality of the light. It influences the illumination angle and light efficiency.
          Optic120º
        • Internal temperature range in which the product can operate efficiently and safely. It is important to ensure its reliability under different usage conditions.
          Working Temperature-30 °C~+45 °C

      • Product Information

        • BrandLyco
        • CertificatesCE, RoHS, UKCA, ENEC
        • Guarantee7 years
        • Product SeriesHBM EVO

      • Materials and Finishes

        • ColourBlack
        • Fitting MaterialAluminium
        • Not IncludedRemote

      • LED Features

        • Measures how accurately a light source displays colours compared to natural light. A high CRI (close to 100) ensures accurate colour rendering.
          Colour Rendering Index80
        • Defines the light tone, from warm white to cool white, measured in Kelvin (K).
          Colour Temperature4000K
        • Estimated lifespan of the product before it loses performance. Based on optimal, non-continuous use, and measured in hours of operation under controlled conditions.
          Hours100.000 hours
        • Light ColourCool White
        • Lumen30000 lm
        • Ratio between light output (lumens) and energy consumed (watts). A high value indicates better efficiency, ideal for saving energy without compromising lighting.
          Luminous Efficiency200 lm/W
        • Number of LEDs480
        • Power Factor0.95

      • Product Data

        • Product FormatHigh Bay Lighting
        • Product typeIndustrial Highbays

      • Driver Information

        • Driver Intensity520 mA - 750 mA
        • Driver Power150 W
        • Voltage level that the driver uses to power the LEDs or electrical components of the product, ensuring their proper functioning.
          Driver Tension180 V-260 V
        • Type Of DriverDALI
      Outdoor Lights

      Key Features

      High-performance industrial LED high bay luminaire featuring 150 W power consumption and delivering 30,000 lumens with exceptional luminous efficacy of 200 lm/W. Equipped with a high-quality SOSEN DALI driver supporting DALI 2 dimming for precise light control and energy efficiency. The light source utilises LUMILEDS SMD2835 LEDs, ensuring reliable performance and a colour temperature of 4000K (cool white) with a CRI of 80 for accurate colour rendering in professional environments. The optic provides a wide 120º beam angle, optimised for uniform illumination in spaces with high ceilings. Robust aluminium housing with IP65 protection rating guarantees resistance to dust and water ingress, suitable for demanding industrial and outdoor conditions. Mechanical impact resistance is ensured with IK08 rating. Designed to operate reliably within a wide ambient temperature range from -20 °C to +50 °C, making it ideal for harsh environments. The luminaire includes a 0.30 m cable and offers a long service life of up to 100,000 hours, backed by a 7-year guarantee, ensuring durability and low maintenance in production and logistics facilities.

      Description

      High-performance industrial LED high bay luminaire delivering 30,000 lumens at 150 W with exceptional luminous efficacy of 200 lm/W. Features robust IP65 ingress protection and IK08 impact resistance for durability in harsh environments. Equipped with LUMILEDS SMD2835 LEDs and a SOSEN DALI driver supporting DALI 2 and push dimming for precise, reliable lighting control. Provides a 4000K cool white light with a CRI of 80 for accurate colour rendering. The optic offers a 120º beam angle optimised for uniform illumination in high-ceiling industrial and warehouse settings. Constructed with a durable aluminium housing for optimal heat dissipation and mechanical strength, ensuring a long operational life of 100,000 hours. Designed to operate reliably within a temperature range of -30 °C to +45 °C, guaranteeing consistent performance and resilience in demanding production and logistics environments.
