Astro Minima Slimline Round Recessed IP65 Fire Rated Fixed Downlight
Ref. Lyco: 61904
Colour Matt White
VAT not included £20.83
£25.00
IN STOCK - Delivered in 1 to 2 working days
(2)5 out of 5 stars
30 Day Return
Under our Change Your Mind Guarantee you can return your item within 30 days for a refund using our hassle free return portal.
For more information view our Returns policy.
Want your items fast?
Check our delivery cut-off times below:
Mon – Thu: Order before 8:45 PM for 24/48h delivery.
Friday: Order before 3:00 PM for 24/48h delivery.
Full conditions here: Delivery methods.
100% secure payments
At Lyco we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation
Up to 5 year warranty
Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.
You will find the exact product warranty in the technical details.
Dimensions
- Diameter100 mm
- Height130 mm
- Cut Out Dimensions86mm
Downloads
PDF Datasheet 129773_284805 EN
Technical Specifications
Mechanical Features
- Fire RatedYesIndicates whether the product or its materials are fire-resistant, enhancing safety in high-temperature or flame-risk areas.
- InstallationRecessed
- IP RatingIP65The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
- LocationIndoor
- Recommended BulbLED GU10 Bulb
Electrical Features
- Electrical Insulation ClassII
- Light SourceGU10 Bulb
- No. Of Lights1
- Replaceable Light SourceYes
- Wattage6 W
Materials and Finishes
- ColourMatt White
- Fitting MaterialSteel
- Not IncludedBulbs
Product Data
- Product FormatFixed Downlight
- Product typeLED Downlight
Product Information
- BrandAstro
- Guarantee3 years
Key Features
Astro Lighting 1249034 Minima Slimline Round Recessed IP65 Fire Rated Fixed Downlight
- IP65 rated fixed downlight suitable for bathrooms, wet rooms, kitchens and other moisture-prone areas.
- Fire rated for 30, 60 & 90-minute, helping to maintain the fire integrity of the ceiling after installation.
- Suitable for Bathroom Zones 1, 2 & 3, making it ideal for showers, bathrooms and utility rooms.
- Compatible with 1 x GU10 LED lamp up to 6W (lamp sold separately).
- Mains voltage fitting – no external LED driver required for quick and simple installation
- Dimmable when used with a compatible dimmable GU10 LED lamp, allowing adjustable lighting levels.
- Slimline recessed profile creates a modern, minimalist appearance with a discreet ceiling finish.
- Class II double insulated for enhanced electrical safety.
- 86mm ceiling cut-out fits many standard downlight installations.
- 150mm minimum recess depth with support for lamps up to 73mm in length.
- 100mm bezel diameter provides a neat finish while covering the cut-out.
- Designed for installation after plastering.
- Clear glass front helps protect the lamp while maintaining excellent light output.
- Durable mild steel construction for long-lasting performance.
- Ideal for residential and commercial applications, including bathrooms, kitchens, hallways, hotels and hospitality projects.
Description
General information about Astro Minima Slimline Round Recessed IP65 Fire Rated Fixed Downlight
This downlight is constructed with a robust steel fitting finished in matt white, combining durability with a discreet aesthetic. It features an IP65 rating, providing protection against dust and water ingress, suitable for demanding indoor environments. The product includes a fire rating of 90 minutes, enhancing safety in installations requiring fire-resistant luminaires. With dimensions of 130 mm depth and a 100 mm diameter, and a cut-out size of 86 mm, it is compact and easy to integrate into ceilings. The downlight is designed for a single GU10 bulb (not included), enabling easy maintenance and bulb replacement.
Use and applications
The Astro Minima Slimline downlight is a solution oriented to indoor environments where fire safety and water resistance are critical, such as offices and residential housing. It fits perfectly in workstations and office zones, thanks to its recessed mounting and IP65 protection, which ensures reliability in spaces requiring dust and moisture resistance. The fire rating supports compliance with safety regulations in these settings.
Designed for the decoration and interior design sector as well as residential housing, this downlight performs well under typical indoor conditions without the need for additional connectivity or smart control features. Its compatibility with GU10 bulbs allows for flexibility in lighting design. The product operates reliably within standard voltage ranges and is suited for environments demanding high safety standards and straightforward installation.
Highlighted specifications
Dimensions: 130 mm x Ø100 mm; Cut-out size: 86 mm; Fire rating: 90 minutes; IP rating: IP65; Material: Steel; Colour: Matt White; Light source: GU10 bulb (not included); Installation type: Recessed.
Installation and maintenance
The downlight is designed for recessed mounting, requiring an 86 mm cut-out in the ceiling. Installation must follow the indicated recessed system to ensure proper fit and fire rating maintenance. The product should be installed by qualified personnel to guarantee compliance with safety standards.
Disconnect the power supply before any intervention. The steel fitting provides mechanical protection during installation and use. The GU10 bulb is not included and must be installed separately, allowing for easy replacement and maintenance.
Frequently asked questions
- Is the bulb included with the downlight? — The product requires a GU10 bulb which is not included.
- Can this downlight be used outdoors? — It is designed for indoor use only.
- What is the fire rating duration of this downlight? — It has a fire resistance of 90 minutes.
- Is the downlight compatible with smart home systems? — It does not include connectivity or app control.
